Led Plug Light
2W-14W, 85-265V, 2700K-6400K, Plug in
Jinhui wholesales Led Plug Light from China, Just 200 pieces get wholesale price, right now.
Led Plug Light (Led Plug in Light), with the same base of the traditional PL tube G24, and R7S base, E27, our engineer create series of LED Plug light, from 5W to 20w, it could plug in direct replacing the PL tube in the down light or the flood light. High bright SMD LED emits high lumen efficiency 100lm/w, saves 50% energy than compact fluorescent tube.
Since 2005, it with huge demands from the global markets, like US, Brazil, Russia, Europe, Middle east, and Latin America…
Character:
- It works AC 85V ~ 265V wide voltage, 50~60hz
- New classical design.
- Long lifespan 25,000 hours, no mercury vapor, no UV, no flicker ,Rohs.
- 10W LED plugt light = 15w energy saving PL tube.
- Output 500,000pcs per day.
- OEM for wholesales and importers, ODM for supermarkets Home depot, Walmart, Amzon…
- FCC, CUL, SAA,PSE, SAA,CE,GS, ROHS, SASO,VDE,NOM, ISO90001.
Application:
Widely used in Decorative lighting, accent lighting, closet lighting, ceiling lighting, etc.
Warnings & Cautions: No dimmable
Item: YB7301
Product Name: LED Plug In
Supply Voltage: 85-265V/50-60Hz
Color Temp(K): 2700K ~ 6400K Red/Blue/Green
Diameter:
Base Type: R7S
Material: Aluminium
|
Wattage (W) |
Luminous Flux(lm) |
LED (qty/type) |
Size (DxL mm) |
Carton Meas. (100 pcs) |
| 4 | 300-380 | 18PCS | 5.2*7.8cm | 50*36*19cm |
| 8 | 650-750 | 36PCS | 5.2*11.8cm | 50*36*27cm |
| 11 | 1300-1400 | 72PCS | 5.2*18.9cm | 50*36*40cm |
Item: YB7302
Product Name: LED Plug In
Supply Voltage: 85-265V/50-60Hz
Color Temp(K): 2700K ~ 6400K Red/Blue/Green
Diameter:
Base Type: G24, E27
Material: Aluminium
|
Wattage (W) |
Luminous Flux(lm) |
LED (qty/type) |
Size (DxL mm) |
Carton Meas. (100 pcs) |
| 8 | 720-850 | 40PCS | 143*35*35 | 38*21.5*16cm |
| 10 | 900-1050 | 50PCS | 148*35*35 | 38*21.5*16.8cm |
| 13 | 1150-1300 | 64PCS | 189*35*35 | 38*21.5*20.8cm |
Item: YB7304
Product Name: LED Plug In
Supply Voltage: 85-265V/50-60Hz
Color Temp(K): 2700K ~ 6400K Red/Blue/Green
Diameter:
Base Type: G24, E27
Material: Aluminium
|
Wattage (W) |
Luminous Flux(lm) |
LED (qty/type) |
Size (DxL mm) |
Carton Meas. (100 pcs) |
| 6 | 530-650 | 12PCS | ∮125*39.5*35 | 43*22.5*14.5cm |
| 8 | 720-850 | 16PCS | ∮125*39.5*35 | 43*22.5*14.5cm |
| 11 | 1050-1200 | 22PCS | ∮145*39.5*35 | 43*22.5*16.5cm |
Item: YB7305
Product Name: LED Plug In
Supply Voltage: 85-265V/50-60Hz
Color Temp(K): 2700K ~ 6400K Red/Blue/Green
Diameter:
Base Type: G24, E27
Material: Aluminium
|
Wattage (W) |
Luminous Flux(lm) |
LED (qty/type) |
Size (DxL mm) |
Carton Meas. (100 pcs) |
| 6 | 530-650 | 12PCS | 35.3x146 | 43*22.5*16.5cm |
| 8 | 720-850 | 16PCS | 35.3x167 | 43*22.5*18.5cm |
| 11 | 1050-1200 | 22PCS | 35.3x176 | 43*22.5*19.5cm |
Item: YB7401
Product Name: LED Plug In
Supply Voltage: 85-265V/50-60Hz
Color Temp(K): 2700K ~ 6400K Red/Blue/Green
Diameter: 49mm
Base Type: G9, G4
Material: PC
|
Wattage (W) |
Luminous Flux(lm) |
LED (qty/type) |
Size (DxL mm) |
Carton Meas. (100 pcs) |
| 2 | 150 | COB | 31x 66 | 22.5*22*14.5cm |
Item: YB7402
Product Name: LED Plug In
Supply Voltage: 85-265V/50-60Hz
Color Temp(K): 2700K ~ 6400K Red/Blue/Green
Diameter: 49mm
Base Type: G9, G4
Material: PC
|
Wattage (W) |
Luminous Flux(lm) |
LED (qty/type) |
Size (DxL mm) |
Carton Meas. (100 pcs) |
| 2 | 150 | COB | 31x 66 | 22.5*22*14.5cm |
Item: YB7010
Product Name: Gu24 SMD 11W LED Plug Light
- New unique design Energy Saving 220V PF0.6 GU24 SMD 11W LED PL Light
- Efficient lighting, replace ESL PL lamp ( energy saving lamp PL lamp )
- 35% energy saving compared with compact fluorescent light
- Less replacement to save maintenance cost
- Standard IEC size, Standard lamp holder, compatible with electronic transformer
- Aluminum die-casting housing wrapped by thermal plastic and plastic cover
- Constant current driver
| Model No. | YB7010 - LED PL Light |
| Power | 11W |
| Input Voltage | 85-265V |
| Frequency Range | 50Hz--60Hz |
| Light Source | SMD |
| Luminous Flux | 500lm |
| Luminous Efficiency | 50lm/w |
| Light Body Material | AL wrapped by thermal plastic |
| Light Cover | Plastic |
| Base | Gu24 |
| Color Rendering Index(CRI) | Ra>80 |
| Working Temperature | -20°C~60°C |
| Color Temperature | Warm White(WW):2800-3200K |
| Pure White(PW):4000-4500K | |
| Cool White(CW):6000-6500K | |
| Certificates | CE, UL, GS |
| Dimmable Type | Dimming |
| Carton Size | 52X27X40cm |
| Warranty | 3 years |
| Life Time | 25000h |
Item: YB7011
Product Name: 220V Gx53 SMD 5W 7W Round LED Pl Lamp
- New unique design CE UL 220V GX53 SMD 5W 7W LED PL Lamp
- Efficient lighting, replace ESL PL lamp ( energy saving lamp PL lamp )
- 35% energy saving compared with compact fluorescent light
- Less replacement to save maintenance cost
- Standard IEC size, Standard lamp holder, compatible with electronic transformer
- Aluminum die-casting housing wrapped by thermal plastic and plastic cover
- Constant current driver
| Model No. | YB7011 - LED PL Lamp |
| Power | 5W 7w |
| Input Voltage | 85-265V |
| Frequency Range | 50Hz--60Hz |
| Light Source | SMD |
| Luminous Flux | 350 / 500lm |
| Luminous Efficiency | 70lm/w |
| Light Body Material | AL wrapped by thermal plastic |
| Light Cover | Plastic |
| Base | Gx53 |
| Color Rendering Index(CRI) | Ra>80 |
| Working Temperature | -20°C~60°C |
| Color Temperature | Warm White(WW):2800-3200K |
| Pure White(PW):4000-4500K | |
| Cool White(CW):6000-6500K | |
| Certificates | CE, UL, GS |
| Dimmable Type | Dimmable |
| Carton Size | 52X27X40cm |
| Warranty | 3 years |
| Life Time | 25000h |
